The role of Geocells for Soil Stabilization

Geocells are 3D honeycomb cellular confinement systems used for soil stabilization and reinforcement. They are usually made of high-density polyethylene (HDPE) strips welded together, which open out on site into a panel of cells. The cells are filled with granular material, often from the site, and the cell walls stop the fill from moving sideways under load. That confinement turns loose fill into a stiff, load-spreading layer, which is why geocells are used to build on weak, soft or unstable soils in roads, railways, slopes and other infrastructure.

Geocell technology dates back to the late 1970s, when the U.S. Army Corps of Engineers developed cellular confinement (then called sand grids) to build tactical roads over soft ground. After experimenting with plastic pipe mats, slotted aluminium sheets and prefabricated polymer grids, the Corps settled on the polymer cell; today most geocells are made of HDPE.

Advantages of Geocells:

Geocells are engineered mainly for soil stabilization, and are also used for erosion control on slopes and channels. Their main advantages:

• Strong Structure: The HDPE panel is light, but once filled and compacted, the cells confine the fill so it acts as a stiff mat that spreads wheel or foundation loads over a wider area of the weak soil below.
• Ease of Installation: Panels arrive collapsed, are stretched open and pinned, then filled and compacted. Unskilled labour can install them with ordinary earthmoving equipment, saving time and cost.
• Cost-Efficient: Collapsed panels are compact to transport. Because the confined layer is stiffer, a thinner granular layer or lower-quality local fill can often be used than an unreinforced design would need, and maintenance is reduced.
• Environmentally-Friendly: Geocells use on-site fill, which cuts quarrying and truck movements, and on slopes the cells can be filled with topsoil and vegetated.

What is Geocell reinforcement? What are the primary Geocell applications?

Geocell reinforcement is a ground improvement method. Soft soils deform and fail under heavy loads. Laying geocells filled with compacted granular fill over the soft soil increases the bearing capacity and reduces settlement. The expandable panels hold the infill together, and the confined layer spreads the load.

Main geocell applications:

• Geocells stabilise pavement bases on weak subgrades in the roadway sector, for example on this ground stabilization project in Hosur.
• In the railway sector, they are used in trackbed and formation construction, sometimes with geogrids and geocomposites. See the NWR doubling project.
• On slopes and retaining walls, cellular confinement holds topsoil or stone in place and prevents surface erosion.
• In the oil and gas/energy sector, geocells reinforce access roads, drilling pads and pipeline routes over soft ground.

• They line channels and protect hydraulic structures.
• Perforated geocells also let water drain through the cell walls.

Ocean Geosynthetics is a geocell manufacturer in India, with over two decades of experience making geosynthetic products under quality control guidelines.
